Stauff Standard Series 3/8" Pipe Polyamide Clamp Body
Part # 2172PA
Stauff Standard Series Clamp Body Specifications PDF
Specifications
- Size: 3/8" Pipe
- Group: 2 (Standard Series)
- Material: Polyamide
- Length: 1.65"
- Width: 1.18"
- Height: 1.30"
- Bolt Hole Center to Center: 1.02"
- Bolt Hole: To be used with 1/4-20 UNC or M6
- Max Temperature (Brief Exposure) -40F to 284F
- Operating Temperature (Continuous Exposure) -40F to 248F
Call 1-888-979-0811 or email sales@alabamaindustrialproducts.com with questions about our Stauff clamp bodies
